kicad-symbol

OPA858, OPA855, OPA859

High-speed op-amps from TI, in a somewhat challenging WSON8-package...

OPA858 is a 5.5 GHz GBWP FET-input amplifier (stable at gains >= 7V/V), and the OPA859 looks like a slower 1.8 GHz unity-gain stable version.

OPA855 is a 8 GHz bipolar input opamp, gain >=7V/V.

These should be useful where OPA847 and OPA659 were used previously, e.g. in high-speed transimpedance amplifiers.

Categories
kicad-symbol

LTC1562

LTC1562 quad op-amp for building active filters at 10 kHz to 150 kHz.

Categories
kicad-symbol

LT3045

500mA low-noise voltage regulator LT3045 (in contrast to the older but lower current 200mA LT3042)

Categories
kicad-symbol

BUF602

1 GHz buffer amplifier BUF602.

Categories
kicad-symbol

LT3042

low noise voltage regulator LT3042

Categories
kicad-symbol

AD8015 transimpedance amplifier

AD8015, 10 kOhm transimpedance 240 MHz bandwidth photodiode amplifier.

Categories
kicad-symbol

SFP Connector

20pin SMD connector + cage for SFP transceiver.

Categories
kicad-symbol

ONET1191P

ONET1191P, Limiting amplifier for up to 11 Gbps.

Categories
kicad-symbol

THS3491

THS3491 looks like an interesting op-amp for distribution amplifiers and in general for LF/HF work. However it turns out it is a bit finicky about the feedback resistors (high resistance values are stable but noisy, low values would give low noise but might be unstable). We're sticking with LMH6702 for now..

Categories
kicad-symbol

HMC394 2.2 GHz prescaler

HMC394 is a 2.2 GHz programmable prescaler (5-bit counter) with divide-ratios from /2 to /32.
