Category: kicad-symbol

LTC1562

LTC1562 quad op-amp for building active filters at 10 kHz to 150 kHz.

Posted on January 3, 2020January 3, 2020Categories kicad-symbolLeave a comment on LTC1562

LT3045

500mA low-noise voltage regulator LT3045 (in contrast to the older but lower current 200mA LT3042)

Posted on May 10, 2019May 10, 2019Categories kicad-symbolLeave a comment on LT3045

BUF602

1 GHz buffer amplifier BUF602.

Posted on May 9, 2019May 9, 2019Categories kicad-symbolLeave a comment on BUF602

LT3042

low noise voltage regulator LT3042

Posted on May 7, 2019May 7, 2019Categories kicad-symbolLeave a comment on LT3042

AD8015 transimpedance amplifier

AD8015, 10 kOhm transimpedance 240 MHz bandwidth photodiode amplifier.

Posted on May 3, 2019Categories kicad-symbolLeave a comment on AD8015 transimpedance amplifier

SFP Connector

20pin SMD connector + cage for SFP transceiver.

Posted on April 22, 2019April 22, 2019Categories kicad-symbolTags sfp, transceiverLeave a comment on SFP Connector

ONET1191P

ONET1191P, Limiting amplifier for up to 11 Gbps.

Posted on April 18, 2019April 18, 2019Categories kicad-symbolLeave a comment on ONET1191P

THS3491

THS3491 looks like an interesting op-amp for distribution amplifiers and in general for LF/HF work. However it turns out it is a bit finicky about the feedback resistors (high resistance values are stable but noisy, low values would give low noise but might be unstable). We're sticking with LMH6702 for now..

Posted on April 11, 2019April 11, 2019Categories kicad-symbolLeave a comment on THS3491

HMC394 2.2 GHz prescaler

HMC394 is a 2.2 GHz programmable prescaler (5-bit counter) with divide-ratios from /2 to /32.

Posted on April 11, 2019April 11, 2019Categories kicad-symbolLeave a comment on HMC394 2.2 GHz prescaler

AD9912

DDS with 47-bit tuneable frequency word.

Posted on March 22, 2019March 22, 2019Categories kicad-symbolLeave a comment on AD9912
